Square D HGA36100SA - Molded Case 100A 600V 3-Pole
Square D HGA36100SA - Molded Case 100A 600V 3-Pole

Square D HGA36100SA - Molded Case 100A 600V 3-Pole

Square D
Price
Save $2,418.47
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Square D HGA36100SA is a 3-pole molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. It is rated for 600V AC, 100A continuous current, and provides LI (Long-Time and Instantaneous) protection functions through a thermal magnetic trip mechanism. The breaker measures 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm), weighs 5 lb, and features an I-Line style plug-in connection with terminals accepting AWG 14 to AWG 3/0 aluminum or copper wire. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, with an AIC rating of 35kA at 480V and an operating temperature range of 28-158 °F (-2-70 °C). This breaker is suited for 3-phase industrial applications requiring reliable overcurrent protection and is equipped with a 120Vac shunt trip for remote tripping capability.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial power distribution, overcurrent protection
  • Poles: 3
  • Connection: I-Line Style Plug-In
  • AIC rating: 35kA@480V
  • Phase: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Wire Size: AWG 14...AWG 3/0 aluminium/copper terminal
  • Temp Rating: 28-158 °F (-2-70 °C)
  • Weight: 5 lb
  • Additional Info: complete with 120Vac shunt trip


Product Identification
  • UPC: 785901840787
  • GTIN: 785901840787
