Square D HGA260704 - Molded Case Circuit Breaker 70A 600V 2-Pole
Square D HGA260704 - Molded Case Circuit Breaker 70A 600V 2-Pole

Square D HGA260704 - Molded Case Circuit Breaker 70A 600V 2-Pole

Square D
Price
Save $3,518.32
/
Condition
  • Low stock - 8 items left
  • Backordered, shipping soon
Call for Price
Square D HGA260704 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 70A current rating and a 600V voltage rating, housed within a compact H-frame measuring 163 mm x 104 mm x 86 mm (HxWxD) and weighing 3.001 lb. The breaker utilizes a thermal-magnetic trip unit for both long-time and instantaneous protection, is configured as a 2-pole, single-phase device with an I-Line style plug-in connection, and offers a 35kA interrupting capacity at 480V. It is constructed for a wide operating temperature range of -25 to 70 °C and complies with UL, CSA, NEMA, NOM, and IEC 60947-2 standards, making it suitable for panelboards and switchboards in commercial and industrial facilities.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, H-Frame
  • Voltage Rating: 600V AC
  • Current Rating: 70A
  • Dimensions: 6.4 in (163 mm) H x 4.09 in (104 mm) W x 3.4 in (86 mm) D
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial Panelboards, Switchboards, Commercial Electrical Distribution
  • Phase: 1
  • Poles: 2
  • AIC Rating: 35kA @ 480V
  • Connection: I-Line Style Plug-In
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous
  • Frame Size: H Frame
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Wire Size: AWG 14 to AWG 3/0 (Aluminium/Copper Terminal)
  • Certification: UL, CSA, NOM
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901600954
  • GTIN: 00785901600954
