Square D HGA260351 - Molded Case 35A 2-Pole 600V
Square D HGA260351 - Molded Case 35A 2-Pole 600V

Square D HGA260351 - Molded Case 35A 2-Pole 600V

Square D
Price
Save $683
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D HGA260351 is a 2-pole molded case circuit breaker from the Powerpact family, designed for thermal magnetic protection against overloads and short circuits. It is rated for 600V AC, 35A continuous current, and provides a 35kA interrupting capacity at 480V AC, with long time and instantaneous trip functions. The unit measures 6.4 in x 4.09 in x 3.4 in (163 mm x 104 mm x 86 mm), weighs 3.001 lb, and features an I-Line style plug-in connection accepting AWG 14 to AWG 3/0 aluminum or copper terminals. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, operating within a temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is suited for industrial panelboard applications requiring single-phase, 2-pole protection with a compact frame size.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 35A
  • Dimensions: 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial panelboards, single-phase distribution
  • Switch Type: I-Line Style Plug-In
  • Configuration: 2-Pole
  • Coil Voltage Maximum: Not applicable (thermal magnetic)
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Shipping Dimensions: 6.4 in x 4.09 in x 3.4 in
  • Phase: 1
  • Voltage: 600V
  • Amperage: 35A
  • AIC rating: 35kA@480V
  • Connection: I-Line Style Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: HGA
  • Trip Type: Thermal Magnetic
  • Panel Type: I-Line
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Not specified
  • Panel Style: I-Line
  • Bus Type: I-Line
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: I-Line Plug-In
  • Hz: 50/60 Hz
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: AWG 14...AWG 3/0 aluminium/copper
  • Amperage Maximum: 35A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: I-Line Plug-In
  • Wire Size: AWG 14...AWG 3/0 aluminium/copper
  • Certification: UL, CSA, NOM
  • Circuit Breaker Mounting Style: I-Line Plug-In
  • Terminal Connection: I-Line
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single-phase
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Compatible Frames: Powerpact HGA
  • Installation Type: Plug-In
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: HGA
  • Current Rating: 35A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 785901834137
