Siemens HF328NR - Fusible Disconnect Switch 1200A 240V (NEMA 3R)

Price
Regular price $0.00
Regular price Sale price $0.00
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Siemens HF328NR is a fusible disconnect switch designed for providing visible isolation and overcurrent protection in industrial power distribution systems. It is rated for 240V AC operation with a continuous current rating of 1200A and a high interrupting capacity of 200kA at 240V. The robust, single-configuration unit features a 3-pole design, measures 74.803 x 42.913 x 11.811 inches, and is constructed for durability with a NEMA 3R enclosure suitable for outdoor use. This switch is UL listed and is engineered for compatibility with PAF frames, ensuring reliable integration into established electrical infrastructures. Typical applications include service entrance equipment, motor control centers, and main distribution panels where dependable circuit isolation and Class L fuse protection are required.

Key Features & Specifications
  • Type: Fusible Disconnect Switch, VBII Series, HF Type
  • Voltage Rating: 240V AC
  • Current Rating: 1200A
  • Dimensions: 74.803" H x 42.913" W x 11.811" D
  • Weight: 350.733 lb
  • Standards: UL Listed
  • Applications: Main Distribution, Service Entrance, Motor Control Centers
  • Switch Type: Fusible
  • Configuration: Single
  • Poles: 3
  • AIC Rating: 200kA @ 240V
  • NEMA Rating: 3R
  • Fuse Class: L
  • Compatible Frames: PAF
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643150751
  • GTIN: 00783643150751
