Siemens HF322N is a fusible disconnect switch designed for providing visible isolation and overcurrent protection in three-phase industrial power distribution systems. It features a 60A current rating and a 240V AC voltage rating, housed within a robust NEMA 1 enclosure measuring 16.62 x 10.37 x 8.67 inches and weighing 18.001 lb. The switch is UL listed and operates reliably across a temperature range of -25°C to 70°C (-13°F to 158°F). Its 200kA interrupting rating at 240V and compatibility with Class R fuses and HED frames make it suitable for motor control centers, HVAC systems, and industrial machinery protection.
Key Features & Specifications
Type: Fusible Disconnect Switch, VBII Series, HF type
Voltage Rating: 240V AC
Current Rating: 60A
Configuration: Single, 3-Pole
Dimensions: 16.62 x 10.37 x 8.67 inch
Weight: 18.001 lb
Standards: UL listed, NEMA 1 enclosure rating
Applications: Industrial power distribution, motor control, HVAC
Switch Style: Fusible
Phase: 3
AIC Rating: 200kA @ 240V
Fuse Class: R
Temp Rating: -25°C to 70°C (-13°F to 158°F)
Compatible Frames: HED
Country of Origin: Mexico
Product Identification
UPC: 783643150294
GTIN: 00783643150294
