Siemens HED43B035 - Molded Case Circuit Breaker 45A 480V 3P
Siemens HED43B035 - Molded Case Circuit Breaker 45A 480V 3P

Siemens HED43B035 - Molded Case Circuit Breaker 45A 480V 3P

Siemens
Price
Save $4,076.61
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Siemens HED43B035 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 45A current rating and a 480V AC voltage rating, housed within a compact 125A/ED frame measuring 3" x 6.34" and weighing 3.671 lb. This thermal-magnetic breaker is UL Listed and HACR rated, ensuring compliance with industry safety standards for use in SB switchboards and Sentron panelboards within industrial and commercial facilities.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Long Time and Instantaneous Trip Functions
  • Voltage Rating: 480V AC
  • Current Rating: 45A
  • Frame Size: 125A/ED
  • Poles: 3
  • AIC Rating: 42kA @ 480V
  • Connection: Load Side Lug, Lug In Panelboard
  • Phase Connection: ABC
  • Wire Size: AWG 10 to AWG 1/0 (Copper/Aluminum)
  • MCM Size: Minimum 1/0 AWG (Al) / 3 AWG (Cu), Maximum 2 AWG (Al) / 3 AWG (Cu)
  • Standards/Certification: HACR Rated, UL Listed
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 3 in x 6.34 in
  • Weight: 3.671 lb
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643210134
  • GTIN: 00783643210134
