Siemens HED42B035 - Molded Case Breaker 35A 480V 2-Pole
Siemens HED42B035 - Molded Case Breaker 35A 480V 2-Pole

Siemens HED42B035 - Molded Case Breaker 35A 480V 2-Pole

Siemens
Price
Save $1,119.35
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Siemens HED42B035 is a molded case circuit breaker designed for reliable overcurrent protection in industrial power distribution systems. It provides a 35A current rating and 480V voltage rating with a 42kA interrupting capacity at 480V for robust fault protection. The breaker features a 125A/ED frame, a two-pole thermal magnetic trip unit for long-time and instantaneous (LI) protection, and is constructed for lug-in panelboard installation with load side lugs compatible with 10 AWG to 1/0 AWG wire. It is HACR rated and UL listed, ensuring compliance with key industry standards for safety and performance. This standard breaker is typically applied within Sentron panelboards and SB switchboards for single-phase ABC connection systems, operating reliably in ambient temperatures from -25°C to 70°C.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Standard
  • Voltage Rating: 480V AC
  • Current Rating: 35A
  • Frame Size: 125A/ED
  • AIC Rating: 42kA @ 480V
  • Poles: 2
  • Phase: 1
  • Connection: Lug In Panelboard, Load Side Lug
  • Trip Functions: LI (Long-Time and Instantaneous)
  • Wire Size Range (MCM): 10 AWG to 1/0 AWG
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards: HACR Rated, UL Listed
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Phase Connection: ABC
  • Weight: 2.8 lb
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643209985
  • GTIN: 00783643209985
