Siemens HED42B015 is a molded case circuit breaker designed for reliable overcurrent and short-circuit protection in commercial and industrial electrical systems. It features a 15A current rating and a 480V voltage rating, housed within a compact 2" x 6.35" (50.8mm x 161.3mm) frame with a thermal-magnetic trip unit providing long-time and instantaneous (LI) protection functions. This high-interrupting capacity (42kA @ 480V) breaker is constructed for use with load-side lugs in panelboards and switchboards, complying with UL 489 and IEC 60947-2 standards for safety and performance. Its operational temperature range of -25°C to 70°C ensures reliability in diverse environments, making it suitable for protecting feeder and branch circuits in Sentron series panelboards and SB switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip (LI)
  • Voltage Rating: 480V AC
  • Current Rating: 15A
  • Dimensions: 2 in x 6.35 in (50.8 mm x 161.3 mm)
  • Standards: UL 489, IEC 60947-2
  • Applications: SB Switchboards, Sentron Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Coil Voltage Maximum: Not Applicable
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: Not Specified
  • Phase: 1
  • Voltage: 480V
  • Amperage: 15A
  • AIC rating: 42kA @ 480V
  • Connection: Lug In Panelboard
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip (LI)
  • Frame Size: 125A/ED
  • Trip Type: Thermal-Magnetic
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Breaker Type: High Interrupting Capacity
  • Control Voltage Minimum: Not Applicable
  • Control Voltage Maximum: Not Applicable
  • MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu); Max. Wire Size 10 AWG
  • Metal Type: Not Specified
  • Panel Style: Not Specified
  • Bus Type: Not Specified
  • Fuse Class: Not Applicable
  • Insulation Temperature: Not Specified
  • Inductance: Not Specified
  • Impedance: Not Specified
  • Barrels: Not Applicable
  • Class Rating: Not Specified
  • Diameter: Not Specified
  • Velocity: Not Applicable
  • Clip Center: Not Applicable
  • Class: Not Specified
  • Mounting: Panel Mount
  • Hz: 50/60 Hz
  • Coil Material: Not Applicable
  • Horse Power: Not Specified
  • Aux Contacts: None
  • CPT: Not Applicable
  • Full Load Amps: Not Specified
  • Dist Voltage: Not Specified
  • Bucket Size: Not Applicable
  • Bucket Style: Not Applicable
  • Bucket Type: Not Applicable
  • Full Load Amp Maximum: Not Specified
  • Full Load Amp Minimum: Not Specified
  • Enclosure: Molded Case
  • Relay Style: Not Applicable
  • Coil Voltage Minimum: Not Applicable
  • Wire: See MCM Size
  • Amperage Maximum: 15A
  • Amperage Minimum: 15A
  • Nema Rating: Not Specified
  • Switch Style: Toggle
  • Wire Size: See MCM Size
  • Certification: UL 489, IEC 60947-2
  • Circuit Breaker Mounting Style: Fixed
  • Terminal Connection: Load Side Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Any
  • Standards: UL 489, IEC 60947-2
  • Compatible Frames: 125A/ED
  • Installation Type: Panelboard
  • Item QTY: 1
  • Nema Starter Size: Not Applicable
  • Breaker Frame: 125A/ED
  • Current Rating: 15A
  • Reverse Standoff Voltage: Not Applicable
  • Watts: Not Specified
  • Peak Pulse Current: Not Applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not Applicable
  • Breakdown Voltage (VBR@IT) (V): Not Applicable
  • Polarity: Not Applicable
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: Not Applicable
  • On-State Current: Not Applicable
  • Weight: 2.5 lb
  • Family: Sentron Series
  • Country of Origin: Mexico
