Square D HDP36060 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 60A current rating and a 600V voltage rating, housed within a compact H-frame measuring 163 mm H x 104 mm W x 86 mm D and weighing 4.9 lb. The breaker utilizes a thermal-magnetic trip unit for long-time and instantaneous protection, with bolt-on connection via lug and terminal nut for secure installation. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, making it suitable for use in industrial panels, motor control centers, and commercial electrical service equipment.

Key Features & Specifications
  • Type: HDP Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 6.4 in (163 mm) H x 4.09 in (104 mm) W x 3.4 in (86 mm) D
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial Power Distribution, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • Amperage: 60A
  • AIC Rating: 18kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: H
  • Trip Type: Thermal Magnetic
  • Panel Type: Industrial
  • Breaker Type: Molded Case
  • Temp Rating: 28-158 °F (-2-70 °C)
  • MCM Size: Min. 14 AWG, Max. 3/0 AWG (Cu/Al)
  • Terminal Connection: Lug, Terminal Nut
  • Wire Size: AWG 14 to AWG 3/0 (Aluminium/Copper)
  • Certification: UL, CSA, NOM
  • Mounting: Fixed
  • Hz: 50/60 Hz
  • Enclosure: Open
  • Circuit Breaker Mounting Style: Fixed
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Compatible Frames: Powerpact H-Frame
  • Installation Type: Fixed
  • Breaker Frame: H
  • Operating Temperature Maximum Celsius: 70 °C


Product Identification
  • Manufacturer: Schneider Electric
  • Family: Powerpact
  • Country of Origin: Mexico
