Square D HDM36150 - Molded Case 150A 600V 3-Pole Breaker
Square D HDM36150 - Molded Case 150A 600V 3-Pole Breaker

Square D HDM36150 - Molded Case 150A 600V 3-Pole Breaker

Square D
Price
Save $1,152.93
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D HDM36150 is a 3-pole molded case circuit breaker designed for thermal magnetic protection in industrial power distribution systems. It is rated for 600V AC, 150A continuous current, and provides LI (Long-Time and Instantaneous) trip functions with an AIC rating of 18kA at 480V. The unit measures 6.4 in x 4.09 in x 3.4 in (H x W x D), weighs 4.17 lb, and features a bolt-on connection with aluminum/copper terminals accepting AWG 14 to AWG 3/0 wire. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, making it suitable for commercial and industrial panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic
  • Voltage Rating: 600V AC
  • Current Rating: 150A
  • Dimensions: 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight: 4.17 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial power distribution, panelboards, switchboards, motor control centers
  • Poles: 3
  • Connection: Bolt-On
  • Protection: Thermal Magnetic (LI - Long-Time and Instantaneous)
  • Wire Size: AWG 14...AWG 3/0 aluminium/copper terminal
  • AIC rating: 18kA@480V
  • Phase: 3
  • Certification: UL, CSA, NOM
  • Functions: LI - Long-Time and Instantaneous
  • Country of Origin: United States


Product Identification
  • UPC: 785901943044
  • GTIN: 0785901623212
