Square D HDA36125SA - Molded Case 125A 600V 3-Pole Breaker
Square D HDA36125SA - Molded Case 125A 600V 3-Pole Breaker

Square D HDA36125SA - Molded Case 125A 600V 3-Pole Breaker

Square D
Price
Save $2,867.88
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Square D HDA36125SA is a Powerpact molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. This three-pole unit is rated for 125A continuous current at 600VAC, with an interrupting capacity of 18kA at 480VAC. The breaker measures 6.4 inches in height, 4.09 inches in width, and 3.4 inches in depth, weighing 5 lb, and features an I-Line style plug-in connection with thermal-magnetic protection (LI functions: long-time and instantaneous trip). It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, and is certified by UL, CSA, and NOM. This unit is suitable for three-phase applications, accepting wire sizes from AWG 14 to AWG 3/0 in aluminum or copper terminals, and is manufactured in the United States by Schneider Electric.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Powerpact family, thermal-magnetic protection
  • Voltage Rating: 600VAC
  • Current Rating: 125A
  • Dimensions: 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial power distribution, motor protection, feeder circuits
  • Poles: 3
  • Phase: 3
  • AIC rating: 18kA@480V
  • Connection: I-Line Style Plug-In
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Wire Size: AWG 14...AWG 3/0 aluminium/copper terminal
  • Certification: UL, CSA, NOM
  • Weight: 5 lb
  • Country of Origin: United States


Product Identification
  • UPC: 7.85902E+11
