Square D HDA261505 - 3-Pole 150A Molded Case Breaker
Square D HDA261505 - 3-Pole 150A Molded Case Breaker

Square D HDA261505 - 3-Pole 150A Molded Case Breaker

Square D
Price
Save $2,735.19
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
The Square D HDA261505 is a 3-pole molded case circuit breaker from Schneider Electric, designed to provide thermal-magnetic overcurrent protection for industrial electrical systems. It is rated for 600V AC, 150A continuous current, with an AIC rating of 18kA at 480V, and features LI (Long-Time and Instantaneous) trip functions. This bolt-on breaker measures 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) and weighs 3.001 lb, accepting wire sizes from AWG 14 to AWG 3/0 in aluminum or copper. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, making it suitable for single-phase applications in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic
  • Voltage Rating: 600V AC
  • Current Rating: 150A
  • Poles: 3
  • Connection: Bolt-On
  • AIC rating: 18kA@480V
  • Phase: 1
  • Functions: LI - Long-Time and Instantaneous
  • Wire Size: AWG 14...AWG 3/0 aluminium/copper terminal
  • Dimensions: 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight: 3.001 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification: UL, CSA, NOM
  • Country of Origin: United States


Product Identification
  • UPC: 078590155835
