Siemens HCP367VJ600 is a fusible safety switch designed for providing reliable circuit protection and isolation in industrial power distribution systems. It is rated for 600V AC operation with a continuous current rating of 800A across its three poles, housed in a robust panel-mount enclosure weighing 82.001 lb. The switch is engineered to meet rigorous industry standards, featuring a 200kA interrupting rating at 480V and a NEMA 1 enclosure rating. Its typical applications include service entrance equipment, motor control centers, and main distribution panels where high fault current protection is required.
Key Features & Specifications
Type: Fusible safety switch, panel mount, Sentron Series HCP type
Voltage Rating: 600V AC
Current Rating: 800A
Configuration: Single, 3-pole
Phase: 3
AIC Rating: 200kA @ 480V
Fuse Class: J
Compatible Frames: MHP
NEMA Rating: 1
Switch Style: Fusible
Weight: 82.001 lb
Standards: Designed for industrial power distribution applications
Applications: Service entrance, main distribution panels, motor control centers
