Siemens HCP367V - Fusible Safety Switch 800A@600V (200kA AIC, NEMA 1)

Siemens HCP367V is a fusible safety switch designed for high-current industrial power distribution systems, providing reliable circuit protection with its 200kA@480V AIC rating. The switch handles up to 800A continuous current across three poles with a 600V AC voltage rating, housed in a rugged NEMA 1 enclosure weighing 150 lb for panel mounting. Compliant with industrial safety standards, this Sentron Series component features Class L fuse compatibility and MHP frame integration for heavy-duty applications like motor control centers and main service disconnects.

Key Features & Specifications

• Type: Fusible safety switch, 3-pole single configuration
• Voltage Rating: 600V AC
• Current Rating: 800A
• Dimensions: Panel-mounted (exact dimensions not specified)
• Standards: NEMA 1 enclosure rating
• Applications: Industrial power distribution, motor control centers
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• Phase: 3
• AIC Rating: 200kA@480V
• Fuse Class: L
• Compatible Frames: MHP
• Weight: 150 lb

Product Identification

• UPC: 783643006805
• GTIN: 00783643006805
