Mersen H300100CF00 - Medium Voltage Fuse 5500V 390A (Dual-Barrel Bolt-In Design)

Mersen H300100CF00 is a medium voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. This H-type fuse features a 5500V voltage rating and 390A current rating, providing reliable overcurrent protection for high-power applications. Constructed with a dual-barrel design and 3-inch diameter, the fuse utilizes bolt-in connections for secure installation in electrical equipment. It complies with industry standards for medium voltage protection applications. Typical applications include motor control centers, transformers, and industrial switchgear where high-interrupting capacity is required.

Key Features & Specifications

• Type: H-type medium voltage current-limiting fuse with dual-barrel construction
• Voltage Rating: 5500V AC
• Current Rating: 390A
• Dimensions: 3-inch diameter
• Connection: Bolt In
• Barrels: 2
• Weight: 19 lb
• Item Subcategory: Medium Voltage
• Standards: Industry standards for medium voltage protection
• Applications: Industrial power distribution, motor control centers, transformers, switchgear

Product Identification

• GTIN: 00782001306755
