Mersen H300096CF00 - Medium Voltage Current-Limiting Fuse 5500V 230A (Bolt-In Connection)

Mersen H300096CF00 is a medium voltage current-limiting fuse designed for protecting electrical distribution equipment in industrial power systems. This H-type fuse features a 5500V voltage rating and 230A current rating, providing reliable overcurrent protection for medium voltage applications. Constructed with a single-barrel design and bolt-in connection, the fuse measures 2.63 inches in diameter and weighs 11 pounds, ensuring robust physical durability. It complies with industry standards for medium voltage protection devices and is typically employed in motor control centers, transformers, and industrial switchgear applications where high-interrupting capacity and current limitation are required.

Key Features & Specifications

• Type: H-type medium voltage current-limiting fuse with single-barrel construction
• Voltage Rating: 5500V AC
• Current Rating: 230A
• Dimensions: 2.63 inches diameter
• Weight: 11 lb
• Connection: Bolt In
• Barrels: 1
• Item Subcategory: Medium Voltage
• Standards: Industry standards for medium voltage protection
• Applications: Industrial power distribution, motor control centers, transformers, switchgear

Product Identification

• GTIN: 00782001306731
