Ocal GUAB36G - Non-Fusible Disconnect 600V 60A
Ocal GUAB36G - Non-Fusible Disconnect 600V 60A

Ocal GUAB36G - Non-Fusible Disconnect 600V 60A

Ocal
Price
Save $-291.28
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Ocal GUAB36G is a general-use air conditioning disconnect switch designed for safe and reliable isolation of HVAC equipment. This unit is rated for 600 volts AC and 60 amps, providing robust overcurrent protection in a compact, rugged enclosure. Constructed with a NEMA 3R-rated, rainproof metallic housing, it measures approximately 6.5 inches in height, 4.5 inches in width, and 3.5 inches in depth, weighing 5.19 pounds. It complies with UL 98 standards for disconnect switches and is suitable for commercial and industrial applications requiring a non-fusible, pull-out style switch for motor and compressor circuits.

Key Features & Specifications
  • Type: Non-fusible, pull-out air conditioning disconnect switch
  • Voltage Rating: 600 VAC
  • Current Rating: 60 Amps
  • Dimensions: 6.5 in H x 4.5 in W x 3.5 in D
  • Standards: UL 98
  • Applications: HVAC equipment isolation, commercial/industrial motor circuits
  • Switch Type: Pull-out
  • Configuration: 2-pole, 3-wire
  • Enclosure: NEMA 3R, metallic, rainproof
  • Mounting: Surface mount
  • Phase: Single phase
  • Horse Power: 7.5 HP at 240V, 15 HP at 480V
  • Wire Size: #14 AWG to #4 AWG
  • Terminal Connection: Copper/aluminum rated
  • Frequency Rating: 60 Hz
  • Certification: UL listed
  • Weight: 5.19 lb


Product Identification
  • UPC: Not available
  • GTIN: Not available
