Mersen GSC1 - GSC Class Time-Delay Fuse 1A@250V (100kA AIC)

Mersen GSC1 is a low-voltage time-delay fuse designed for circuit protection in industrial electrical systems. It features a 250V AC rating with a 1A current capacity and 100A interrupting rating at 250V, housed in a compact 0.79-inch diameter ferrule-connected barrel construction. UL Listed and CSA Certified, this GSC-class fuse meets stringent safety standards for use in control circuits, transformers, and motor branch circuits where delayed response to temporary overloads is required.

Key Features & Specifications

• Type: GSC-class time-delay fuse with ferrule connection
• Voltage Rating: 250V AC
• Current Rating: 1A
• Dimensions: 0.79" diameter x 1.5" length (standard GSC size)
• Standards: UL Listed, CSA Certified
• Applications: Control circuits, transformers, motor protection
• AIC rating: 100kA @ 250V
• Connection: Ferrule
• Barrels: 1
• Velocity: Time Delay

Product Identification

• UPC: 78200176575
• GTIN: 00782001765750
