Ferraz Shawmut GSA6 - Time-Delay Fuse 6A@250V (200kA AIC)

Ferraz Shawmut GSA6 is a low-voltage time-delay fuse designed for circuit protection in industrial applications. It features a 250V AC rating with a 6A current capacity and 200kA interrupting rating at 250V, housed in a compact 1-1/4" ferrule-connected barrel with 14mm diameter. The UL/CSA-certified fuse employs a time-delay characteristic for overload protection while maintaining a lightweight 0.006 lb construction.

Key Features & Specifications

• Type: GSA series time-delay low-voltage fuse
• Voltage Rating: 250V AC
• Current Rating: 6A
• Dimensions: 1-1/4" length, 14mm diameter
• Connection: Ferrule
• Barrels: 1
• AIC Rating: 200kA@250V
• Certification: UL, CSA
• Weight: 0.006 lb

Product Identification

• UPC: 782001764180
• GTIN: 00782001764180
