Ferraz Shawmut GSA3 - GSA Time-Delay Fuse 3A@250V (100kA AIC)

Ferraz Shawmut GSA3 is a low-voltage time-delay fuse designed for circuit protection in industrial applications. It features a 250V AC rating with a 3A current capacity and 100kA interrupting capacity at 250V, housed in a compact 1-1/4" ferrule-style body with 14mm diameter. The CSA/UL-listed fuse employs a single-barrel construction with time-delay characteristics for overload protection. Compliant with North American safety standards, it's commonly used in motor control centers, transformers, and power distribution systems.

Key Features & Specifications

• Type: GSA series time-delay low-voltage fuse
• Voltage Rating: 250V AC
• Current Rating: 3A
• Dimensions: 1-1/4" length, 14mm diameter
• Connection: Ferrule
• Barrels: 1
• AIC Rating: 100kA @ 250V AC
• Certification: CSA, UL
• Applications: Motor protection, transformers, power distribution

Product Identification

• UPC: 782001764142
• GTIN: 00782001764142
