Bussmann GMF-3 - GMF Fuse 3A 300V (10kA AIC Rating)
Bussmann GMF-3 - GMF Fuse 3A 300V (10kA AIC Rating)
Bussmann GMF-3 - GMF Fuse 3A 300V (10kA AIC Rating)
Bussmann GMF-3 - GMF Fuse 3A 300V (10kA AIC Rating)

Bussmann GMF-3 - GMF Fuse 3A 300V (10kA AIC Rating)

Bussmann
Price
Save $14.84
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann GMF-3 is a low voltage fuse designed for circuit protection in industrial electrical systems. It features a 3A current rating and 300V voltage rating with 10kA interrupting capacity at 300V AC for reliable overcurrent protection. The fuse construction includes a single-barrel design with 0.63-inch diameter ferrule connections and measures 2-1/4 inches in length. It complies with CE, CSA Certification Class 1422-01, and UL 248-14 Guide JDYX standards for safety and performance. Typical applications include industrial control circuits, motor protection, and electrical distribution equipment where precise current limitation is required.

Key Features & Specifications
  • Type: GMF low voltage fuse with single-barrel construction
  • Voltage Rating: 300V AC/DC
  • Current Rating: 3A
  • Dimensions: 2-1/4 inches length x 0.63 inches diameter
  • Standards: CE, CSA Certification Class 1422-01, UL 248-14 Guide JDYX
  • Applications: Industrial control circuits, motor protection, electrical distribution
  • Connection: Ferrule
  • Barrels: 1
  • AIC rating: 10kA@300Vac
  • Weight: 1 lb
  • Certification: CE, CSA, UL


Product Identification
  • UPC: 051712716826
  • GTIN: 00051712716826
