Bussmann GMA-200-R - GMA Series Fuse 200A (35kA AIC @ 250V)

The Bussmann GMA-200-R is a low-voltage current-limiting fuse designed for overcurrent protection in industrial electrical systems. It features a 200A current rating and 250V voltage rating with a 35kA interrupting capacity at 250V for reliable circuit protection. The fuse employs a single-barrel ferrule connection design with compact 5mm diameter x 20mm dimensions and weighs 1 lb for straightforward installation. Certified to UL, CSA, CE, and PSE standards, this GMA series fuse meets rigorous safety requirements for industrial applications including motor protection, transformer circuits, and power distribution systems where high-current interruption capability is essential.

Key Features & Specifications

• Type: GMA series current-limiting fuse with ferrule connection, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 200A
• Dimensions: 5mm diameter x 20mm length
• Standards: CE, UL Guide JDYX (File E19180), CSA Certification Class 1422-01 (File 53787), PSE Approval
• Applications: Industrial motor protection, transformer circuits, power distribution systems
• AIC rating: 35,000A @ 250V
• Connection: Ferrule
• Barrels: 1
• Certification: CE, UL, CSA, PSE
• Family: GMA Series
• Item Subcategory: Low Voltage Fuse
• Country of Origin: China
• Weight: 1 lb
• Diameter: 5mm

Product Identification

• UPC: 05171264790
• GTIN: 00051712647908
