Eaton Cutler-Hammer GHB2060 - 60A 2-Pole Circuit Breaker (480V, 14kA AIC)
Eaton Cutler-Hammer GHB2060 - 60A 2-Pole Circuit Breaker (480V, 14kA AIC)
Eaton Cutler-Hammer GHB2060 - 60A 2-Pole Circuit Breaker (480V, 14kA AIC)
Eaton Cutler-Hammer GHB2060 - 60A 2-Pole Circuit Breaker (480V, 14kA AIC)

Eaton Cutler-Hammer GHB2060 - 60A 2-Pole Circuit Breaker (480V, 14kA AIC)

Cutler Hammer
Price
Save $395.46
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton Cutler-Hammer GHB2060 is a molded case circuit breaker designed for providing reliable overcurrent protection in commercial and industrial electrical systems. It features a 60A current rating and a 480V AC voltage rating, housed within a compact 100/GHB frame with dimensions of 2.63 in (D) x 4 in (H) x 2 in (W) and a weight of 1.15 lb. This thermal magnetic breaker, certified to UL 516 and CSA standards, offers 14kA interrupting capacity and is constructed for bolt-on connection to Eaton Powerline panelboards, operating effectively in ambient temperatures from -2°C to 70°C (28°F to 158°F).

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Long-Time and Instantaneous (LI) Trip
  • Voltage Rating: 480V AC
  • Current Rating: 60A
  • Frame Size: 100/GHB
  • Poles: 2
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On, Screw Clamp Terminal
  • Wire Size Range: 10 to 1/0 AWG
  • Phase: 1
  • Operating Temperature: -2°C to 70°C (28°F to 158°F)
  • Dimensions: 2.63 in (Depth) x 4 in (Height) x 2 in (Width)
  • Weight: 1.15 lb
  • Standards & Certification: UL 516, UL Listed, CSA Certified
  • Compatible Panel Type: Eaton Powerline Panelboards


Product Identification
  • UPC: 786679172407
  • GTIN: 00786679172407
