Mersen GDL6 - GDL Time-Delay Fuse 6A@250V (200A AIC)

Mersen GDL6 is a low-voltage time-delay fuse designed for circuit protection in industrial electrical systems. Rated for 250V AC/DC operation with a 6A current capacity, it features a compact 1-1/4" cylindrical design with 0.25" diameter and 1-barrel construction. The fuse meets CSA and UL safety standards with a 200A interrupting capacity at 250V, making it suitable for motor control circuits, transformers, and power distribution panels requiring delayed response to temporary overloads.

Key Features & Specifications

• Type: GDL series time-delay fuse with ceramic body
• Voltage Rating: 250V AC/DC
• Current Rating: 6A
• Dimensions: 1-1/4" length x 0.25" diameter
• Weight: 0.01 lb
• Standards: CSA, UL listed
• Applications: Motor protection, control circuits, power distribution
• AIC rating: 200A@250V
• Velocity: Time-delay characteristic
• Barrels: 1
• Certification: CSA, UL

Product Identification

• UPC: 782001763343
• GTIN: 00782001763343
