Mersen GDL1 - Time Delay Fuse 1A 250V (35kA AIC Rating)

Mersen GDL1 is a low-voltage time-delay fuse designed for circuit protection in industrial applications. It features a 250V AC voltage rating with a 1A current rating and 35kA interrupting capacity at 250V. The fuse construction includes a single-barrel design with 0.25" diameter and 1-1/4" length, weighing 5.19 lb. It complies with UL and CSA standards for safety and reliability. Typical applications include motor protection, transformer circuits, and industrial control panels where time-delay characteristics prevent nuisance tripping during temporary overload conditions.

Key Features & Specifications

• Type: GDL time-delay fuse, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 1A
• Dimensions: 1-1/4" length, 0.25" diameter
• Standards: UL, CSA certified
• Applications: Motor protection, transformer circuits, industrial control panels
• AIC rating: 35kA @ 250V
• Velocity: Time Delay
• Barrels: 1
• Weight: 5.19 lb
• Certification: CSA, UL

Product Identification

• UPC: 782001763206
• GTIN: 00782001763206
