Ferraz Shawmut GDG315/1000 - Low Voltage Fuse 315A@250V (35kA AIC)

Ferraz Shawmut GDG315/1000 is a low-voltage fuse designed for circuit protection in industrial electrical systems. This GDG series fuse features a 250V AC voltage rating and 315A current rating with a high interrupting capacity of 35kA@250Vac for reliable short-circuit protection. The compact 20mm ferrule-style fuse body is constructed with precision-engineered components, meeting international safety standards for low-voltage applications. Its 5mm diameter design and 0.005 lb weight make it suitable for space-constrained installations while maintaining robust performance. Typical applications include motor control centers, power distribution panels, and industrial equipment requiring 250V circuit protection.

Key Features & Specifications

• Type: GDG series low-voltage ferrule fuse
• Voltage Rating: 250V AC
• Current Rating: 315A
• Dimensions: 20mm length x 5mm diameter
• Weight: 0.005 lb
• Connection: Ferrule
• AIC Rating: 35kA@250Vac
• Standards: International low-voltage fuse compliance
• Applications: Motor controls, power distribution, industrial equipment

Product Identification

• UPC: 78200176435
• GTIN: 00782001764357
