Mersen GAB3/4 - Fast-Acting Fuse 3A 250V (35kA AIC Rating)

Mersen GAB3/4 is a low voltage fuse designed for circuit protection in industrial applications. It features a 250V voltage rating with a 3A current rating and 35kA interrupting capacity at 250V for reliable overcurrent protection. The fuse utilizes a fast-acting design with single-barrel ferrule connection construction measuring 1-1/2 inches in length and 0.25 inches in diameter, weighing 0.006 lb. It complies with UL and CSA certification standards for safety and performance assurance. Typical applications include protection of control circuits, instrumentation, and small power supplies in industrial environments.

Key Features & Specifications

• Type: GAB fast-acting fuse with ferrule connection
• Voltage Rating: 250V AC
• Current Rating: 3A
• Dimensions: 1-1/2 in length x 0.25 in diameter
• Standards: UL, CSA certified
• Applications: Industrial control circuits, instrumentation protection
• AIC rating: 35,000A @ 250V
• Connection: Ferrule
• Barrels: 1
• Velocity: Fast Acting
• Certification: UL, CSA
• Weight: 0.006 lb

Product Identification

• UPC: 78200176005
• GTIN: 00782001760052
