Bussmann FWX-80A - Current-Limiting Fuse 80A (200kA AIC @ 250V)

Bussmann FWX-80A is a low-voltage current-limiting fuse designed for robust circuit protection in industrial applications. It features a 250V AC voltage rating with an 80A current rating and provides high interrupting capacity with a 200kA AIC rating at 250V. The fuse construction utilizes a single-barrel design with stud connections and measures 3-1/8 inches in length with a 1.22-inch diameter, weighing 1 lb. It meets rigorous industry standards with CE, CSA, and UL certifications, ensuring reliable performance in demanding environments including industrial control panels, motor branch circuits, and power distribution systems.

Key Features & Specifications

• Type: FWX Series current-limiting fuse, single barrel
• Voltage Rating: 250V AC
• Current Rating: 80A
• Dimensions: 3-1/8 in length, 1.22 in diameter
• Standards: CE, CSA Certified, UL Recognized
• Applications: Industrial control panels, motor protection, power distribution
• Connection: Stud
• Barrels: 1
• AIC rating: 200kA@250V
• Weight: 1 lb
• Certification: CE, CSA Certified, UL Recognized
• Family: FWX Series
• Item Subcategory: Low Voltage Fuse

Product Identification

• UPC: 051712150613
• GTIN: 00051712150613
