Bussmannn FWX-70A - Low-Voltage Fuse 70A (200kA AIC @250V)

Bussmannn FWX-70A is a low-voltage fuse designed for high-interrupting-capacity circuit protection in industrial applications. Rated for 250V AC/DC systems with a 70A current rating, it features a stud connection and single-barrel construction with a 1.22-inch diameter and 3-1/8-inch length. Certified to UL, CSA, and CE standards, this fuse delivers 200kA AIC protection in a compact 1 lb package, suitable for motor control centers, switchgear, and power distribution systems.

Key Features & Specifications

• Type: FWX-series low-voltage fuse with stud connection
• Voltage Rating: 250V AC/DC
• Current Rating: 70A
• Dimensions: 3-1/8 in length, 1.22 in diameter
• Weight: 1 lb
• Standards: UL Recognized, CSA Certified, CE compliant
• AIC Rating: 200kA@250V
• Connection: Stud
• Barrels: 1
• Certification: CE, CSA, UL
• Applications: Industrial power distribution, motor protection, switchgear

Product Identification

• UPC: 051712150606
• GTIN: 00051712150606
