Bussmann FWX-300A - Low Voltage Fuse 300A (200kA AIC @ 250V)

Bussmann FWX-300A is a low-voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 300A current rating and 250V voltage rating with an impressive 200kA interrupting capacity at rated voltage. The fuse construction utilizes a single-barrel design with stud connections and measures 1.5 inches in diameter by 3-27/32 inches in length, weighing 1 lb. Certified to CE, CSA, and UL standards, this FWX series fuse meets rigorous safety and performance requirements for industrial applications including motor control centers, power distribution panels, and heavy equipment protection.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse, single-barrel construction with stud connection
• Voltage Rating: 250V AC
• Current Rating: 300A
• Dimensions: 1.5" diameter × 3-27/32" length
• Standards: CE, CSA Certified, UL Recognized
• Applications: Industrial power distribution, motor control centers, heavy equipment protection
• AIC rating: 200kA@250V
• Connection: Stud
• Barrels: 1
• Weight: 1 lb
• Family: FWX Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712150699
• GTIN: 00051712150699
