Bussmann FWP-80B - Low Voltage Fuse 80A 700V (200kA AIC Rating)

Bussmann FWP-80B is a low voltage fuse designed for providing reliable overcurrent protection in industrial electrical systems. This 80A current rated fuse operates with a 700V voltage rating and features a 200kA interrupting capacity at 700V for robust fault protection. The fuse construction includes a single barrel design with stud connections and measures 4-13/32 inches in length with a 0.95-inch diameter, weighing 5 lb for substantial physical presence. It carries CE, CSA Certified, and UL Recognized certifications, ensuring compliance with international safety standards. Typical applications include industrial control panels, motor circuits, and power distribution systems where high-performance circuit protection is required.

Key Features & Specifications

• Type: Low Voltage Fuse, FWP Series, single barrel construction with stud connection
• Voltage Rating: 700V
• Current Rating: 80A
• Dimensions: 4-13/32 inches length, 0.95-inch diameter
• Standards: CE, CSA Certified, UL Recognized
• Applications: Industrial control panels, motor circuits, power distribution systems
• AIC rating: 200kA@700V
• Connection: Stud
• Barrels: 1
• Certification: CE, CSA Certified, UL Recognized
• Weight: 5 lb
• Family: FWP Series
• Country of Origin: Hungary

Product Identification

• UPC: 051712796026
• GTIN: 00051712796026
