Bussmann FWP-70B - FWP Series Fuse 70A 700V (200kA AIC Rating)

Bussmann FWP-70B is a low-voltage fuse designed for industrial circuit protection applications requiring high interrupting capacity. This 70A rated fuse operates at 700V with an impressive 200kA interrupting rating, providing reliable overcurrent protection in demanding environments. The fuse features a single-barrel construction with stud connections and measures 4-13/32 inches in length with a 0.95-inch diameter, weighing 5 pounds for robust physical characteristics. It carries CE, CSA, and UL certifications, ensuring compliance with international safety standards for industrial electrical systems. Typical applications include motor control centers, industrial control panels, and power distribution equipment where high-fault current protection is essential.

Key Features & Specifications

• Type: FWP Series low-voltage fuse with single-barrel construction
• Voltage Rating: 700V AC
• Current Rating: 70A
• Dimensions: 4-13/32 inches length, 0.95 inches diameter
• Weight: 5 lb
• Standards: CE, CSA Certified, UL Recognized
• Applications: Industrial control panels, motor control centers, power distribution
• Connection: Stud
• Barrels: 1
• AIC rating: 200kA@700V
• Certification: CE, CSA Certified, UL Recognized
• Family: FWP Series
• Country of Origin: Hungary

Product Identification

• UPC: 051712796019
• GTIN: 00051712796019
