Bussmann FWP-300A - FWP Series Fuse 300A (200kA@700V AIC Rating)

Bussmann FWP-300A is a low-voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 300A current rating and 700V voltage rating with exceptional 200kA interrupting capacity at rated voltage. The fuse construction utilizes a single-barrel design with stud connections and measures 5-3/32 inches in length with a 2-inch diameter, weighing 1 lb for secure installation. Certified to UL, CSA, and CE standards, this FWP series fuse meets rigorous safety requirements for industrial applications including motor control centers, switchgear, and power distribution equipment where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: FWP series current-limiting fuse, single barrel construction
• Voltage Rating: 700V AC
• Current Rating: 300A
• Dimensions: 5-3/32 inch length, 2 inch diameter
• Standards: UL Recognized, CSA Certified, CE compliant
• Applications: Industrial power distribution, motor control centers, switchgear
• AIC rating: 200kA@700V
• Connection: Stud type
• Barrels: 1
• Weight: 1 lb
• Family: FWP Series
• Item Subcategory: Low Voltage Fuse

Product Identification

• UPC: 051712150415
• GTIN: 00051712150415
