Bussmannn FWP-175A - Low Voltage Fuse 175A (200kA@700V Interrupting Capacity)

Bussmannn FWP-175A is a low-voltage fuse designed for high-current circuit protection in industrial applications. It features a 700V voltage rating and 175A current rating, with a robust stud connection and single-barrel construction for reliable performance. The fuse measures 5-3/32 inches in length with a 1.5-inch diameter and weighs 1 lb, built to withstand demanding environments. Certified to CE, CSA, and UL standards, it offers 200kA interrupting capacity at 700V for critical fault protection. Typical applications include motor control centers, switchgear, and power distribution systems requiring durable overcurrent protection.

Key Features & Specifications

• Type: FWP series low-voltage fuse with stud connection
• Voltage Rating: 700V AC
• Current Rating: 175A
• Dimensions: 5-3/32 in length, 1.5 in diameter
• Weight: 1 lb
• Standards: CE, CSA Certified, UL Recognized
• Applications: Motor control centers, switchgear, power distribution
• AIC rating: 200kA@700V
• Connection: Stud
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712150385
• GTIN: 00051712150385
