Bussmannn FWP-125A - FWP Series Fuse 125A (200kA@700V Interrupt Rating)

Bussmannn FWP-125A is a low-voltage fuse designed for high-current circuit protection in industrial applications. It features a 700V AC/DC voltage rating and a 125A current rating, with a robust stud connection and single-barrel construction for reliable performance. The fuse measures 5-3/32 inches in length with a 1.5-inch diameter and is constructed to meet CE, CSA, and UL standards, offering a 200kA interrupting capacity at 700V. Its durable design ensures protection in demanding environments such as power distribution systems, motor control centers, and heavy machinery applications.

Key Features & Specifications

• Type: FWP series low-voltage fuse with stud connection
• Voltage Rating: 700V AC/DC
• Current Rating: 125A
• Dimensions: 5-3/32 in length, 1.5 in diameter
• Weight: 1 lb
• Standards: CE, CSA Certified, UL Recognized
• Applications: Power distribution, motor protection, industrial equipment
• AIC Rating: 200kA @ 700V
• Connection: Stud
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712150361
• GTIN: 00051712150361
