Bussmann FWH-80A - FWH Series Fuse 80A 500V (200kA AIC)

Bussmann
Price
Save $255.40
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FWH-80A is a low-voltage, current-limiting fuse designed for providing high-interrupting capacity protection in industrial power circuits. It features a 500V AC voltage rating and an 80A current rating, housed in a robust, single-barrel construction with bolt-in connections for secure installation. The fuse is built to a diameter of 0.75 inches and a length of 4.6 inches, ensuring reliable performance and compliance with CE, CSA, and UL standards. Its 200kA interrupting rating at 500V AC makes it suitable for safeguarding motor control centers, service entrance equipment, and industrial distribution panels against short-circuit faults.

Key Features & Specifications
  • Type: FWH Series, Low Voltage, Current-Limiting, Bolt-In Fuse
  • Voltage Rating: 500V AC
  • Current Rating: 80A
  • Dimensions: 4.6 in L x 1.12 in H x 1.8 in W (0.75 in Diameter)
  • Weight: 0.2 lb
  • Standards: CE, CSA Certified, UL Recognized
  • Applications: Motor Control Centers, Service Entrance, Industrial Distribution
  • AIC rating: 200kA @ 500V AC
  • Connection: Bolt-In
  • Barrels: 1
  • Certification: CE, CSA Certified, UL Recognized


Product Identification
  • UPC: 051712150064
  • GTIN: 00051712150064
