Bussmannn FWH-40A - FWH Series Fuse 40A 500V (200kA AIC)

Bussmannn FWH-40A is a low-voltage fuse designed for high-performance circuit protection in industrial applications. This bolt-in fuse features a 500V AC voltage rating and 40A current rating, with a robust 200kA interrupting capacity at 500V AC for reliable fault protection. The fuse measures 3-3/16 inches in length with a 0.75-inch diameter, constructed as a single-barrel design with UL, CE, and CSA certifications for compliance with international safety standards. Its industrial-grade construction makes it suitable for motor control centers, switchgear, and power distribution systems requiring high interrupting capacity protection.

Key Features & Specifications

• Type: FWH series bolt-in fuse, single barrel design
• Voltage Rating: 500V AC
• Current Rating: 40A
• Dimensions: 3-3/16" length x 0.75" diameter
• Weight: 1 lb
• Standards: UL Recognized, CE, CSA Certified
• Applications: Industrial power distribution, motor control centers, switchgear
• AIC rating: 200kA@500Vac
• Connection: Bolt-In
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712150019
• GTIN: 00051712150019
