Bussmann FWH-250A - FWH Series Fuse 250A (200kA AIC)

Bussmann
Price
Save $353.10
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FWH-250A is a low-voltage current-limiting fuse designed for protecting electrical circuits and equipment from short-circuit faults. It features a 250A current rating and a 500V AC voltage rating, with a high 200kA interrupting capacity at its rated voltage. The fuse is constructed as a single-barrel unit with stud connections, measuring 1.69 in x 1.61 in x 4.52 in (L/D x H x W) and weighing 0.52 lb. It complies with CE, CSA, and UL standards for industrial safety and is typically applied in motor protection, feeder circuits, and industrial power distribution systems.

Key Features & Specifications
  • Type: FWH Series, Low Voltage, Current-Limiting, Single Barrel, Stud Connection
  • Voltage Rating: 500V AC
  • Current Rating: 250A
  • Dimensions: 1.69 in x 1.61 in x 4.52 in (Length/Depth x Height x Width)
  • Standards: CE, CSA Certified, UL Recognized
  • Applications: Motor Protection, Feeder Circuits, Industrial Power Distribution
  • AIC rating: 200kA @ 500V
  • Connection: Stud
  • Barrels: 1
  • Diameter: 1.5 in
  • Weight: 0.52 lb


Product Identification
  • UPC: 051712150149
  • GTIN: 00051712150149
