Bussmann FWH-150A - FWH Series Fuse 150A 500V (200kA AIC)

Bussmann
Price
Save $351.47
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FWH-150A is a low-voltage, current-limiting fuse designed for the protection of industrial electrical equipment and conductors. It features a 150A current rating and a 500V AC voltage rating, with a high 200kA interrupting capacity at its rated voltage. The fuse is constructed as a single-barrel, bolt-in unit with a body diameter of 0.75 inches and overall dimensions of 3.701" L x 10" H x 1.181" W, weighing 0.34 lb. It complies with major industry standards, including UL, CSA, and CE certifications, and is typically applied in motor branch circuits, feeder mains, and service entrance equipment requiring robust short-circuit protection.

Key Features & Specifications
  • Type: FWH Series, low-voltage current-limiting fuse, single barrel, bolt-in connection
  • Voltage Rating: 500V AC
  • Current Rating: 150A
  • Dimensions: 3.701 in (L) x 10 in (H) x 1.181 in (W)
  • Standards: UL, CSA, CE
  • Applications: Industrial equipment protection, motor circuits, feeder mains, service entrances
  • AIC rating: 200kA @ 500V AC
  • Connection: Bolt-In
  • Barrels: 1
  • Diameter: 0.75 in
  • Weight: 0.34 lb
  • Family: FWH Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 051712150118
  • GTIN: 00051712150118
