Bussmann
Price
Save $926.88
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FRS-R-60 is a low-voltage current-limiting fuse designed for branch circuit and feeder protection in industrial electrical systems. It provides a 60A current rating and a 600V AC voltage rating, housed in a compact 5.5-inch long, single-barrel body with a 1.06-inch diameter. The fuse is constructed to meet RK5 class standards, offering a high 200kA interrupting rating at 600V for superior short-circuit protection, and carries CE, CSA, and UL 248-12 certifications. Its typical applications include protecting motor circuits, transformers, and other electrical equipment where time-delay and current-limiting characteristics are required.

Key Features & Specifications
  • Type: Fusetron FRS-R, time-delay, current-limiting, low-voltage fuse
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 5.5 in L x 1.84 in H x 1.84 in W
  • Standards: CE, CSA Certification Class 1422-01, UL 248-12 Guide JDDZ
  • Applications: Industrial branch circuit and feeder protection for motors, transformers, and cables
  • AIC rating: 200kA @ 600V
  • Class Rating: RK5
  • Barrels: 1
  • Diameter: 1.06 in
  • Weight: 0.305 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 051712508391
  • GTIN: 00051712508391
