Bussmann FNQR0.25 - Class CC Fuse 0.25A 600VAC (Time-Delay)
Bussmann FNQR0.25 - Class CC Fuse 0.25A 600VAC (Time-Delay)

Bussmann FNQR0.25 - Class CC Fuse 0.25A 600VAC (Time-Delay)

Bussmann
Price
Save $0
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FNQR0.25 is a Class CC, time-delay, current-limiting fuse designed for advanced circuit protection in industrial applications. This fuse provides reliable overcurrent protection with a 0.25A current rating and a 600VAC voltage rating, featuring a high interrupting capacity of 200,000A. It is constructed as a single-pole ceramic cartridge fuse with a 10.3x38mm mounting size and a slow-blow trip characteristic to handle inrush currents. The FNQR0.25 complies with UL 248-4, CSA Class 1422-01, CE, and RoHS standards. It is typically used for industrial branch circuit protection where robust and reliable performance is required.

Key Features & Specifications
  • Type: Class CC, Time-Delay (Slow Blow), Current-Limiting
  • Amperage: 0.25A
  • Voltage: 600VAC
  • Interrupt Rating: 200,000A @ 600VAC
  • Poles: 1
  • Mounting Type: Cartridge (10.3x38mm)
  • Body Material: Ceramic
  • Series/Frame: FNQ-R (Class CC)
  • Certifications: UL Listed (248-4, Class CC), CSA Certified (Class 1422-01), CE, RoHS Compliant
  • Weight: 5.19 lb


Part Number: FNQR0.25
