Bussmann FNQ-R-5-6/10 - Class CC Fuse 5A 600V (200kA AIC)

Bussmann FNQ-R-5-6/10 is a Class CC low-voltage fuse designed for circuit protection in industrial and commercial applications. It features a 600V AC rating with a 5A current rating and a high interrupting capacity of 200kA at 600V for reliable overcurrent protection. The fuse has a compact cylindrical design with a 0.41-inch diameter and 1-1/2-inch length, constructed with durable materials for harsh environments. It meets CE, UL-248-4 Guide JDDZ, and CSA Class 1422-01 standards for safety and performance. Typical applications include motor control centers, transformers, and power distribution equipment requiring Class CC protection.

Key Features & Specifications

• Type: FNQ Class CC time-delay fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 5A
• Dimensions: 1-1/2 in length x 0.41 in diameter
• Standards: CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
• Applications: Industrial power distribution, motor protection, control circuits
• AIC rating: 200kA@600V
• Class Rating: CC
• Weight: 1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712582438
• GTIN: 00051712582438
