Bussmann FNQ-R-1-1/4 - Class CC Fuse 1A (200kA AIC @600V)

Bussmann FNQ-R-1-1/4 is a Class CC low-voltage fuse designed for circuit protection in industrial and commercial applications. It features a 600V AC rating with a 1A current rating and a high interrupting capacity of 200kA at 600V, ensuring reliable overcurrent protection. The fuse has a compact cylindrical design with a 0.41-inch diameter and 1-1/2-inch length, constructed for easy installation in standard fuse holders. It meets CE, UL-248-4, and CSA Class 1422-01 standards for safety and performance. Typical applications include control circuits, transformers, and motor branch circuits requiring precise protection.

Key Features & Specifications

• Type: FNQ Class CC time-delay fuse with single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 0.41" diameter x 1-1/2" length
• Standards: CE/UL-248-4 Guide JDDZ, CSA Class 1422-01
• Applications: Industrial control circuits, transformers, motor protection
• Class Rating: CC
• AIC Rating: 200kA@600V
• Weight: 1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712496940
• GTIN: 00051712496940
