Bussmann FNM-9 - FNM Time-Delay Fuse 9A 250V (200kA AIC)

Bussmann
Price
Save $565.54
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FNM-9 is a low-voltage, time-delay fuse designed for branch circuit and feeder protection in industrial control panels and equipment. It is rated for 250V AC/DC systems with a 9A current rating and a high 200kA interrupting capacity at 250V. The fuse features a compact, single-barrel ferrule non-rejection design with dimensions of 0.39" x 1.44" x 0.39" (LxHxW) and a 0.41" diameter, constructed for reliable performance. It complies with key industry standards including UL 248-14 (Guide JDYX) and is certified to CSA Class 1422-01 and CE. Typical applications include protecting motors, transformers, and conductors where sustained overload conditions are expected.

Key Features & Specifications
  • Type: FNM Series, time-delay, low-voltage fuse with ferrule non-rejection connection
  • Voltage Rating: 250V AC/DC
  • Current Rating: 9A
  • Dimensions: 0.39 in x 1.44 in x 0.39 in (Length/Depth x Height x Width)
  • Diameter: 0.41 in
  • Weight: 0.2 lb
  • Standards: Certified to CE, CSA Class 1422-01, UL-248-14 Guide JDYX
  • AIC Rating: 200kA @ 250V
  • Class Rating: 1422-01
  • Connection: Ferrule Non-Rejection
  • Barrels: 1
  • Country of Origin: Mexico


Product Identification
  • UPC: 051712520904
  • GTIN: 00051712520904
