Bussmann FNM-8/10 is a low-voltage, time-delay fuse designed for branch circuit and feeder protection in industrial control panels and equipment. It is rated for 250V AC/DC systems with a 8A current rating and a high 35kA interrupting capacity at its rated voltage. The fuse features a compact, single-barrel ferrule non-rejection design with dimensions of 0.39" x 1.44" x 0.39" and a 0.41" diameter, constructed for reliable performance. It complies with key industry standards including UL 248-14 and CSA Class 1422-01, bearing CE certification. This fuse is typically applied in motor control circuits, transformers, and other inductive loads where inrush current tolerance is required.

Key Features & Specifications
  • Type: FNM Series, time-delay, low-voltage fuse with ferrule non-rejection connection
  • Voltage Rating: 250V AC/DC
  • Current Rating: 8A
  • Dimensions: 0.39 in (L) x 1.44 in (H) x 0.39 in (W)
  • Diameter: 0.41 in
  • Weight: 0.2 lb
  • Standards: CE, CSA Class 1422-01, UL-248-14 Guide JDYX
  • AIC Rating: 35,000 Amps @ 250V
  • Class Rating: 1422-01
  • Connection: Ferrule Non-Rejection
  • Barrels: 1
  • Country of Origin: Mexico


Product Identification
  • UPC: 051712520089
  • GTIN: 00051712520089
