Bussmann FNM-25 - Low Voltage Fuse 25A (250V, 10kA AIC)

Bussmann FNM-25 is a low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 250V AC/DC operation with a 25A current capacity, it features a compact ferrule non-rejection design measuring 1-1/2 inches in length and 0.41 inches in diameter. The fuse meets CE, CSA Class 1422-01, and UL-248-14 standards with a 10kA interrupting capacity at 250V, ensuring reliable protection against short circuits. Its single-barrel construction and Class 1422-01 rating make it suitable for motor control centers, panelboards, and industrial control equipment requiring precise overcurrent protection.

Key Features & Specifications

• Type: FNM series ferrule non-rejection fuse
• Voltage Rating: 250V AC/DC
• Current Rating: 25A
• Dimensions: 1-1/2 in length, 0.41 in diameter
• Weight: 1 lb
• Standards: CE, CSA Class 1422-01, UL-248-14 Guide JDYX
• Applications: Motor controls, panelboards, industrial equipment
• AIC Rating: 10kA@250V
• Connection: Ferrule non-rejection
• Barrels: 1
• Class Rating: 1422-01

Product Identification

• UPC: 051712522250
• GTIN: 00051712522250
