Bussmann FNM-12 - FNM Time-Delay Fuse 12A 250V

Bussmann
Price
Save $411.55
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann FNM-12 is a low-voltage, time-delay fuse designed for protecting control circuits, transformers, and motors against overloads and short circuits. It features a 12A current rating and a 250V AC voltage rating, with a compact ferrule non-rejection design measuring 1.5 inches in length and 0.41 inches in diameter. Constructed as a single-barrel fuse, it complies with CE, CSA Class 1422-01, and UL-248-14 standards and offers an interrupting rating of 10kA at 250V for reliable performance in industrial panelboards and machinery.

Key Features & Specifications
  • Type: Low-voltage, time-delay, single-barrel fuse with ferrule non-rejection connection
  • Voltage Rating: 250V AC
  • Current Rating: 12A
  • Dimensions: 1.5 in L x 0.41 in H x 0.41 in W (38.1 mm x 10.4 mm x 10.4 mm)
  • Diameter: 0.41 in (10.4 mm)
  • Weight: 0.2 lb (0.09 kg)
  • Standards: CE, CSA Class 1422-01, UL-248-14 Guide JDYX
  • AIC Rating: 10,000 Amps @ 250V
  • Class Rating: 1422-01
  • Connection: Ferrule Non-Rejection
  • Barrels: 1
  • Applications: Protection for control circuits, transformers, motors, and industrial equipment


Product Identification
  • UPC: 051712521208
  • GTIN: 00051712521208
