Bussmann FNA-9 - Fast-Acting Fuse 9A 125V (10kA AIC Rating)

Bussmann FNA-9 is a midget fast-acting fuse designed for overcurrent protection in low-voltage circuits. Rated for 125V AC/DC systems with a 9A current capacity, it features a compact 1-1/2" length and 0.41" diameter ceramic body construction. Certified to UL-248-12, CSA Class 1422-01, and CE standards, this 10kA interrupting capacity fuse is commonly used in industrial control panels, appliances, and power distribution equipment requiring reliable circuit protection.

Key Features & Specifications

• Type: Fast-acting ceramic body fuse (FNA series)
• Voltage Rating: 125V AC/DC
• Current Rating: 9A
• Dimensions: 1-1/2" length x 0.41" diameter
• Weight: 1.1 lb
• Standards: UL-248-12, CSA Class 1422-01, CE
• Applications: Industrial controls, appliances, power distribution
• Class Rating: Midget
• Barrels: 1
• AIC rating: 10kA@125V
• Country of Origin: Mexico

Product Identification

• UPC: 051712713740
• GTIN: 00051712713740
