Bussmann FNA-30 - Midget Fast-Acting Fuse 30A@32V (1kA AIC Rating)

Bussmann FNA-30 is a midget fast-acting fuse designed for low-voltage circuit protection in automotive and industrial applications. Rated for 30A current and 32V DC systems, it features a compact design with 0.82" diameter and 1.52" length, constructed with dual barrels for reliable operation. This fuse meets industry standards with a 1kA interrupting capacity at 32V, making it suitable for protecting sensitive electronics, power distribution systems, and vehicle electrical circuits.

Key Features & Specifications

• Type: Fast-acting FNA series fuse with dual-barrel construction
• Voltage Rating: 32V DC
• Current Rating: 30A
• Dimensions: 0.81" L × 1.52" H × 0.4" W (20.6mm × 38.6mm × 10.2mm)
• Weight: 1.3 lb (0.59 kg)
• Diameter: 0.82" (20.8mm)
• Class Rating: Midget
• AIC Rating: 1kA @ 32V
• Barrels: 2
• Standards: UL/CSA recognized
• Applications: Automotive, power distribution, industrial controls

Product Identification

• UPC: 051712713696
• GTIN: 00051712713696
