Bussmann FNA-3/10 - Fast-Acting Fuse 3A/250V (10kA AIC)

Bussmann FNA-3/10 is a midget fast-acting fuse designed for overcurrent protection in low-voltage circuits up to 250V AC. With a 3A current rating and 10kA interrupting capacity at 250V, it provides reliable circuit protection in compact applications. The fuse features a cylindrical design with 0.41-inch diameter and 1-1/2-inch length, constructed to meet UL-248-12, CSA Class 1422-01, and CE standards. Its single-barrel configuration and midget class rating make it suitable for industrial control panels, HVAC systems, and electrical equipment requiring precise overcurrent protection.

Key Features & Specifications

• Type: Fast-acting, single-barrel midget fuse
• Voltage Rating: 250V AC
• Current Rating: 3A
• Dimensions: 1-1/2 in length x 0.41 in diameter
• Weight: 1.1 lb
• Standards: UL-248-12, CSA Class 1422-01, CE
• AIC Rating: 10kA @ 250V
• Class Rating: Midget
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 05171271338
• GTIN: 00051712713382
